Oceanaire OWC6012: 5-Ton Water-Cooled Portable AC
$11,999.00
Quick Quote Request
Buy Direct & Save
"*" indicates required fields
The Oceanaire OWC6012 5-Ton Water-Cooled Portable Air Conditioner delivers 60,100 BTU/hr of cooling for server rooms, manufacturing facilities, and commercial applications. Its water-cooled design eliminates the need for hot-air exhaust ducting.
Key Specifications:
- Cooling Capacity: 60,100 BTU/hr (5 Tons)
- Electrical: 208–230V / Single Phase
- Plug: NEMA 6-30P
- Airflow: 1,950 CFM
- Condensate Pump: Built-In
Available Options:
Nationwide shipping available. Contact us for pricing and availability.
Resources and Downloads
The Oceanaire OWC6012 5-Ton Water-Cooled Portable Air Conditioner delivers 60,100 BTU/hr of cooling capacity for demanding commercial and industrial applications. Designed for enclosed spaces where traditional hot-air exhaust ducting is impractical, this portable air conditioner uses a water-cooled condenser to remove heat through a suitable building water supply and return system.
Operating on 208–230V / 60Hz single-phase power with a NEMA 6-30P plug, the OWC6012 combines high-capacity cooling, 1,950 CFM of airflow, electronic temperature controls, and an automatic condensate pump in one heavy-duty portable unit.
Whether you need emergency cooling for a server room, supplemental cooling for manufacturing equipment, or temporary air conditioning during HVAC maintenance, the Oceanaire OWC6012 offers a powerful solution without requiring conventional condenser exhaust ducting.
Key Features of the Oceanaire OWC6012
- 60,100 BTU/hr Cooling Capacity: Delivers approximately 5 tons of cooling for demanding commercial and industrial applications.
- Water-Cooled Condenser: Rejects heat through a water supply and return system, eliminating the need for hot-air exhaust ducting.
- 208–230V Single-Phase Operation: Operates on 208–230V / 60Hz single-phase electrical power with a NEMA 6-30P plug.
- High-Capacity Airflow: Delivers up to 1,950 CFM of conditioned airflow.
- Commercial Scroll Compressor: Equipped with a 5 HP scroll compressor for commercial cooling applications.
- Built-In Condensate Pump: Automatically removes collected condensation with up to 20 feet of vertical lift.
- Electronic Temperature Controls: Features a solid-state controller with a large LED display.
- Six-Speed Fan Control: Automatic fan operation with manual override allows greater control over airflow.
- Portable Industrial Design: Swivel casters with front locking wheels allow convenient positioning.
- Washable Air Filter: Removable electrostatic filter simplifies routine cleaning and maintenance.
- R-410A Refrigerant: Uses R-410A refrigerant in a self-contained refrigeration system.
- Safety Features: Includes condensate overflow alerts and pressure protection.
- Manufacturer Warranty: 1-year limited full-product warranty plus 4 additional years of compressor coverage, subject to manufacturer terms.
Common Applications for the Oceanaire OWC6012
Server Rooms and Data Center Cooling
Server rooms, telecommunications facilities, and data centers generate substantial heat from continuously operating electronic equipment.
In many IT environments, routing large hot-air exhaust ducts outdoors can be difficult or impractical.
The Oceanaire OWC6012 addresses this challenge by transferring condenser heat through a suitable water system rather than releasing hot condenser air into the conditioned space.
Its 60,100 BTU/hr cooling capacity makes it an option for larger equipment rooms requiring temporary or supplemental cooling.
Common applications include:
- Emergency cooling during HVAC failures
- Supplemental cooling for server racks
- Cooling during data center maintenance
- Telecommunications and networking equipment rooms
- Temporary cooling during infrastructure upgrades
Proper cooling-load calculations, airflow management, electrical service, and water-system compatibility should be evaluated before installation.
Learn more in our Best Portable Spot Coolers for Server Rooms guide.
Warehouses and Manufacturing Facilities
Manufacturing facilities often contain equipment, machinery, and production processes that generate significant heat.
The OWC6012 can provide targeted cooling for production areas, industrial equipment, assembly operations, and manufacturing workstations.
Its water-cooled design is particularly useful in facilities that have an appropriate water source but lack a convenient way to exhaust condenser air outdoors.
The heavy-duty casters also allow the unit to be repositioned as operational requirements change.
Healthcare Facilities and Laboratories
Healthcare facilities, laboratories, and institutional buildings often have enclosed spaces requiring supplemental or temporary cooling.
The Oceanaire OWC6012 can provide additional cooling capacity for appropriate equipment rooms, laboratories, and support areas where water connections are available.
Because no hot condenser-air exhaust duct is required, the unit can offer installation flexibility in buildings where conventional air-cooled spot coolers would be difficult to accommodate.
Installation in healthcare environments should be evaluated against the facility’s specific operating and environmental requirements.
Emergency and Temporary Commercial Cooling
Unexpected air conditioning failures can interrupt business operations and expose sensitive equipment to elevated temperatures.
The OWC6012 can help provide temporary cooling during HVAC repairs, equipment replacements, renovations, and emergency cooling situations.
Its 5-ton nominal capacity makes it suitable for evaluating higher-load temporary cooling applications where smaller spot coolers may not provide enough capacity.
Explore additional applications in our Temporary Climate Control Solutions collection.
Oceanaire OWC6012 Technical Specifications
| Specification | Oceanaire OWC6012 |
|---|---|
| Cooling Capacity | 60,100 BTU/hr (5 Tons) |
| Cooling Type | Water-Cooled Portable Air Conditioner |
| Power Supply | 208–230V / 60Hz / Single Phase |
| Rated Current | 23.7 Amps |
| Inrush Current | 165 Amps |
| Power Consumption | 5,000 Watts |
| Plug Type | NEMA 6-30P |
| Cooling Airflow (High) | 1,950 CFM |
| Compressor Type | Scroll |
| Compressor Horsepower | 5 HP |
| Compressor LRA | 158 Amps |
| Energy Efficiency Ratio | 12.0 EER |
| Refrigerant | R-410A |
| Refrigerant Charge | 52 oz |
| Condenser Water Flow at 60°F Inlet | 3.8 GPM |
| Condenser Water Flow at 85°F Inlet | 15.0 GPM |
| Water Inlet Connection | 5/8″ Male Flare |
| Water Outlet Connection | 5/8″ Male Flare |
| Condensate Drain Connection | 3/8″ Male Flare |
| Condensate Pump | Built-In Automatic |
| Condensate Pump Lift | Up to 20 Feet Vertical |
| Cooling Ambient Operating Range | 65°F–105°F |
| Dimensions (W × D × H) | 28.2″ × 29.2″ × 53.2″ |
| Weight | 375 lbs |
| Mobility | Swivel Casters with Front Locks |
| Air Filter | Washable Electrostatic |
| Controls | Electronic with 6-Speed Fan |
| Warranty | 1-Year Product / 5-Year Total Compressor Coverage |
Manufacturer specifications are subject to change. Cooling capacity, electrical performance, and condenser water requirements depend on operating conditions. Confirm current requirements before installation.
How Does the Oceanaire OWC6012 Water-Cooled System Work?
Unlike traditional air-cooled spot coolers, the Oceanaire OWC6012 uses water to reject the heat removed from the conditioned space.
During operation, the unit draws warm room air across its evaporator coil and delivers conditioned air back into the room.
Heat collected by the refrigeration system is transferred to water flowing through the condenser. The warmed water then leaves the unit through the return connection.
This means the OWC6012 does not require a large hot-air exhaust duct.
However, it does require a suitable water supply and return arrangement capable of handling the condenser’s operating requirements.
Water Supply Requirements
The OWC6012 requires adequate water flow based on the entering water temperature and operating conditions.
Published condenser water-flow figures include:
- 3.8 GPM with 60°F entering water
- 15.0 GPM with 85°F entering water
The correct water source, pressure, temperature, flow rate, and discharge arrangement must be verified before installation.
Water consumption and operating costs depend on the type of water system used.
Water Connections
The standard OWC6012 uses threaded water connections:
- Water inlet: 5/8-inch male flare
- Water outlet: 5/8-inch male flare
- Condensate drain: 3/8-inch male flare
Compatible hoses and connection accessories may be required depending on the building’s water infrastructure.
For customers who prefer faster hose connections, Climate Control Solutions also offers the Oceanaire OWC6012QC Quick Connect version.
Electrical Requirements
The OWC6012 operates on 208–230V / 60Hz single-phase electrical power and uses a NEMA 6-30P plug.
The published specifications list a rated current of 23.7 amps.
A compatible, properly rated electrical circuit and receptacle are required. The manufacturer recommends dedicated circuits and appropriate time-delay circuit protection.
Built-In Condensate Pump
The Oceanaire OWC6012 includes an automatic condensate pump with up to 20 feet of vertical lift.
This feature helps simplify condensate management during extended cooling operation.
The pump includes an overflow alert to help protect against excessive collected water.
Condensate should be routed to an approved drainage location.
Optional Accessories for the Oceanaire OWC6012
The OWC6012 supports additional accessories for water connections, air distribution, and installation flexibility.
Water Supply and Return Hoses
Compatible water hoses are essential for connecting the OWC6012 to an appropriate building water system.
The standard OWC6012 uses 5/8-inch male flare water inlet and outlet connections.
Hose length, fittings, temperature ratings, and pressure requirements should be confirmed before ordering.
Contact Climate Control Solutions for compatible hose options and installation accessories.
Quick Connect Water Connection Option
For applications where equipment must be connected, disconnected, or moved frequently, the Oceanaire Quick Connect series offers an alternative to standard threaded water connections.
The Oceanaire OWC6012QC 5-Ton Water-Cooled Portable Air Conditioner features Quick Connect water fittings for convenient setup.
The QC model is a separate configuration and should be selected when Quick Connect functionality is required.
Cold-Air Distribution Accessories
Compatible air-distribution accessories may be available to help direct conditioned air toward selected equipment or work areas.
Contact Climate Control Solutions to confirm the correct accessories for the OWC6012 and the intended installation.
Why Choose the Oceanaire OWC6012?
The Oceanaire OWC6012 combines high-capacity cooling, water-cooled heat rejection, and commercial-grade construction in one portable air conditioning system.
Its 60,100 BTU/hr cooling capacity provides an option for facilities requiring substantial temporary or supplemental cooling.
Unlike air-cooled portable air conditioners, the OWC6012 does not require hot condenser-air exhaust ducting. This can provide a significant advantage in server rooms, laboratories, and enclosed commercial environments where traditional exhaust installations are difficult.
The unit’s built-in condensate pump, electronic controls, washable filter, and locking casters add convenience for commercial applications.
Compare Other Oceanaire Water-Cooled Portable Air Conditioners
Climate Control Solutions offers several Oceanaire models for different cooling capacities and installation requirements:
- Oceanaire OWC3612 – 3-Ton Water-Cooled Portable Air Conditioner — Approximately 36,000 BTU/hr cooling capacity with 208–230V single-phase power.
- Oceanaire OWC2412 – 2-Ton Water-Cooled Portable Air Conditioner — 24,000 BTU/hr cooling capacity for smaller commercial applications.
- Oceanaire OWC6012QC – 5-Ton Quick Connect Water-Cooled Portable AC — Quick Connect hose configuration for temporary installations.
For additional options, browse our Water-Cooled Portable Air Conditioners or visit the Oceanaire Product Collection.
Frequently Asked Questions About the Oceanaire OWC6012
How many BTUs does the Oceanaire OWC6012 provide?
The OWC6012 delivers 60,100 BTU/hr of nominal cooling capacity, approximately 5 tons of refrigeration.
Does the Oceanaire OWC6012 require exhaust ducting?
No. The OWC6012 is water-cooled and rejects condenser heat through its water circuit rather than through a hot-air exhaust duct.
It must, however, be connected to a suitable water supply and return system.
What electrical power does the OWC6012 require?
The OWC6012 operates on 208–230V / 60Hz single-phase power and uses a NEMA 6-30P plug.
Does the OWC6012 require a water connection?
Yes. Water-cooled operation requires an appropriate water source and a means of carrying heated water away from the condenser.
Water flow requirements depend on the entering water temperature and operating conditions.
What is the difference between OWC6012 and OWC6012QC?
The standard OWC6012 uses threaded water connections, while the OWC6012QC features Quick Connect fittings for more convenient hose installation and removal.
Both models provide approximately 5 tons of cooling capacity.
Is the OWC6012 available in three-phase configurations?
Yes. Other models in the OWC60 series include the OWC6032 for 208–230V three-phase power and the OWC6034 for 460V three-phase power.
Can the OWC6012 cool a server room or data center?
Yes. The OWC6012 can provide temporary or supplemental cooling for suitable server rooms and data center support areas when the cooling load, electrical service, airflow, and water-system requirements are appropriate.
Does the OWC6012 include a condensate pump?
Yes. The unit includes an automatic condensate pump with up to 20 feet of vertical lift.
What refrigerant does the Oceanaire OWC6012 use?
The OWC6012 uses R-410A refrigerant.
Can the OWC6012 be used outdoors?
No. OceanAire specifies that the OWC6012 is not approved for outdoor use.
What is the warranty on the Oceanaire OWC6012?
OceanAire provides a 1-year limited full-product warranty with 4 additional years of compressor coverage, subject to the manufacturer’s warranty terms.
Buy the Oceanaire OWC6012 from Climate Control Solutions
Climate Control Solutions supplies Oceanaire water-cooled portable air conditioners and commercial cooling equipment nationwide.
Whether you need a single OWC6012 for a server room or multiple units for a commercial or industrial cooling project, our team can assist with equipment selection, electrical requirements, water connections, and shipping arrangements.
Contact Climate Control Solutions for current pricing, availability, compatible accessories, and bulk-order quotes.
