OceanAire 20ACH6034: 5-Ton Portable Heat Pump & Spot Cooler
$15,999.00
Quick Quote Request
Buy Direct & Save
"*" indicates required fields
The OceanAire 2OACH6034 5-Ton Portable Heat Pump delivers 60,100 BTU/hr of cooling and 53,500 BTU/hr of heating for warehouses, manufacturing facilities, server rooms, and commercial applications. Its 460V three-phase design provides powerful year-round temperature control.
Key Specifications:
- Cooling Capacity: 60,100 BTU/hr (5 Tons)
- Heating Capacity: 53,500 BTU/hr
- Electrical: 460V / Three Phase
- Plug: NEMA L16-20P
- Airflow: 1,950 CFM
- Condensate Pump: Built-In
Optional Accessories:
16″ Ceiling Panel Kit (CK-16) | Dual 8″ Nozzle Kit (2NK-3)
Nationwide shipping available. Contact us for pricing and availability.
Resources and Downloads
The OceanAire 2OACH6034 5-Ton Portable Heat Pump delivers 60,100 BTU/hr of cooling and 53,500 BTU/hr of heating for demanding commercial and industrial environments. Designed for temporary and supplemental climate control, this deluxe portable heat pump is ideal for warehouses, manufacturing facilities, server rooms, equipment rooms, and commercial buildings.
Operating on 460V / 60Hz three-phase power with a NEMA L16-20P plug, the 2OACH6034 combines high-capacity heating and cooling in one mobile system. The unit features a 5 HP scroll compressor, 1,950 CFM of conditioned airflow, electronic temperature controls, washable filters, and a built-in automatic condensate pump.
Whether you need emergency cooling during HVAC maintenance, supplemental heating for a manufacturing facility, or temporary climate control for commercial operations, the OceanAire 2OACH6034 offers year-round flexibility.
Key Features of the OceanAire 2OACH6034
- 60,100 BTU/hr Cooling Capacity: Delivers approximately 5 tons of cooling for commercial and industrial applications.
- 53,500 BTU/hr Heating Capacity: Provides supplemental heating for commercial workspaces and temporary HVAC projects.
- 460V Three-Phase Operation: Designed for facilities equipped with compatible 460V / 60Hz three-phase electrical service.
- NEMA L16-20P Plug: Provides a defined industrial electrical connection for installation planning.
- 5 HP Scroll Compressor: Commercial-grade compressor designed for high-capacity heating and cooling applications.
- High-Capacity Airflow: Delivers 1,950 CFM of conditioned airflow and 2,200 CFM of condenser airflow.
- Automatic Heating and Cooling Changeover: Electronic controls allow the unit to respond to changing temperature requirements.
- Built-In Condensate Pump: Automatically removes collected moisture with up to 20 feet of vertical lift.
- Six-Speed Fan Control: Automatic fan-speed adjustment with manual override.
- Digital Temperature Controls: Solid-state electronic controller with a large LED display.
- Portable Construction: Swivel casters with locking front wheels allow the unit to be repositioned.
- Washable Electrostatic Filters: Removable air filters simplify routine maintenance.
- Safety Features: Includes high-pressure protection, a condensate overflow alert, and a three-phase monitor.
- Optional Accessories: Supports a ceiling panel kit, directional nozzle kit, return-air plenums, and a discharge duct adapter.
- Manufacturer Warranty: 1-year limited product warranty plus 4 additional years of compressor coverage, subject to manufacturer terms.
Indoor use only. The 2OACH6034 is not approved for outdoor operation.
Common Applications for the OceanAire 2OACH6034
Warehouses and Manufacturing Facilities
Warehouses and manufacturing facilities often require supplemental cooling during warmer conditions and additional heating during colder months.
The OceanAire 2OACH6034 provides both capabilities in one portable unit, making it useful for:
- Industrial workstations and production areas
- Manufacturing equipment rooms
- Assembly and packaging operations
- Maintenance facilities
- Commercial warehouse spaces
Its portable construction allows the unit to be relocated as heating and cooling requirements change.
With approximately 5 tons of cooling capacity, it is suitable for evaluating applications that require greater output than smaller portable spot coolers.
Server Rooms and IT Equipment Cooling
Server rooms, networking equipment, and telecommunications facilities generate heat during continuous operation.
The 2OACH6034 can provide temporary or supplemental cooling during HVAC maintenance, equipment upgrades, or unexpected cooling failures.
Its 60,100 BTU/hr cooling capacity makes it an option for larger equipment rooms when the cooling load and installation conditions are appropriate.
Heating mode may also provide flexibility when the unit is used elsewhere in the facility.
Proper condenser exhaust routing, cooling-load calculations, electrical compatibility, and condensate drainage are essential when using portable cooling near sensitive electronic equipment.
Learn more in our Best Portable Spot Coolers for Server Rooms in 2026 guide.
Commercial Offices and Institutional Facilities
The OceanAire 2OACH6034 can provide temporary heating and cooling for commercial buildings, institutional facilities, equipment areas, and other indoor workspaces.
It may be particularly useful when permanent HVAC equipment is undergoing repairs or certain areas need additional heating or cooling capacity.
Temporary and Emergency HVAC Applications
Unexpected HVAC failures can interrupt business operations and expose equipment to undesirable temperatures.
The 2OACH6034 provides a portable heating and cooling solution for suitable emergency and planned temporary applications, including:
- HVAC system repairs
- Equipment replacement
- Commercial renovations
- Seasonal heating and cooling
- Temporary facility climate control
Explore additional equipment in our Portable Heat Pumps collection.
OceanAire 2OACH6034 Technical Specifications
| Specification | OceanAire 2OACH6034 |
|---|---|
| Cooling Capacity | 60,100 BTU/hr (5 Tons) |
| Heating Capacity | 53,500 BTU/hr |
| Cooling Type | Air-Cooled Portable Heat Pump |
| Power Supply | 460V / 60Hz / Three Phase |
| Rated Current | 14.8 Amps |
| Inrush Current | 87 Amps |
| Power Consumption | 6,000 Watts |
| Plug Type | NEMA L16-20P |
| Energy Efficiency Ratio | 10.0 EER |
| Compressor Type | Scroll |
| Compressor Horsepower | 5 HP |
| Compressor LRA | 60 Amps |
| Evaporator Airflow (High) | 1,950 CFM |
| Condenser Airflow | 2,200 CFM |
| Evaporator Fan Motor | 1 HP |
| Condenser Fan Motor | 1 HP |
| Refrigerant | R-410A |
| Refrigerant Charge | 80 oz |
| Condensate Pump | Built-In Automatic |
| Condensate Pump Lift | 20 Feet Vertical |
| Cooling Ambient Range | 65°F–105°F |
| Heating Ambient Range | 40°F–85°F |
| Dimensions (W × D × H) | 28.2″ × 41″ × 54.2″ |
| Net Weight | 520 lbs |
| Filters | Washable Electrostatic |
| Fan Controls | Automatic / Manual, 6 Speeds |
| Electronic Controls | Automatic Heating/Cooling Changeover |
| Mobility | Swivel Casters with Front Locks |
| Outdoor Use | Not Approved |
| Warranty | 1-Year Product / 5-Year Total Compressor Coverage |
Specifications are based on published OceanAire technical literature and may change. Rated capacities are measured under the manufacturer’s specified test conditions. Actual performance depends on temperature, airflow, ducting, and installation.
Installation and Electrical Requirements
The OceanAire 2OACH6034 operates on 460V / 60Hz three-phase electrical power.
The unit uses a NEMA L16-20P locking plug and requires a compatible electrical receptacle and appropriately rated circuit.
Published electrical characteristics include:
- Rated current: 14.8 amps
- Inrush current: 87 amps
- Power consumption: 6,000 watts
OceanAire recommends a dedicated circuit with appropriate time-delay fuses or circuit breakers.
Customers should confirm available electrical service and verify requirements against the equipment nameplate before installation.
Heating and Cooling Operation
The 2OACH6034 provides both heating and cooling through its heat pump system.
Its solid-state electronic controls support automatic changeover between operating modes.
The manufacturer specifies different ambient operating ranges:
- Cooling: 65°F–105°F
- Heating: 40°F–85°F
The unit is designed for indoor use and is not approved for outdoor operation.
Condenser Exhaust and Ventilation
Unlike water-cooled portable air conditioners, the OceanAire 2OACH6034 uses an air-cooled condenser.
During cooling operation, the condenser rejects heat into a separate air stream. Proper routing is necessary to prevent unwanted heat from returning to the conditioned area.
Compatible ceiling panel kits, discharge duct adapters, and flexible ducting can help manage condenser airflow.
For heating operation, the air arrangement must follow the manufacturer’s instructions for the selected mode.
Built-In Condensate Management
The OceanAire 2OACH6034 includes an automatic condensate pump with up to 20 feet of vertical lift.
The pump removes moisture collected during operation and includes an overflow alert.
Condensate should be directed to an appropriate drainage location.
A separate external condensate pump is generally unnecessary for standard installations because the unit already includes one.
Optional Accessories for the OceanAire 2OACH6034
OceanAire offers several optional accessories specifically identified for the 2OACH6034. These accessories can improve airflow distribution, condenser exhaust management, and installation flexibility.
OceanAire 16-Inch Ceiling Panel Kit — CK-16
The OceanAire CK-16 ceiling panel kit is designed to discharge condenser air through a compatible suspended ceiling installation.
This accessory is useful for commercial buildings, server rooms, and equipment areas where condenser exhaust needs to be routed away from the conditioned space.
The receiving ceiling space must be suitable for the condenser airflow and heat load.
Manufacturer Part Number: CK-16
Contact Climate Control Solutions for pricing and availability.
OceanAire Dual 8-Inch Nozzle Kit — 2NK-3
The optional OceanAire 2NK-3 nozzle kit provides two 8-inch directional air outlets.
This accessory allows conditioned air to be directed toward specific equipment, workstations, or localized areas requiring heating or cooling.
Manufacturer Part Number: 2NK-3
Contact Climate Control Solutions for pricing and availability.
OceanAire Evaporator Return-Air Plenum — DEP-16
The DEP-16 return-air plenum is designed for installations where return air needs to be ducted back to the evaporator.
This can provide flexibility when the portable heat pump must be positioned away from the conditioned area.
Manufacturer Part Number: DEP-16
Contact Climate Control Solutions for pricing and availability.
OceanAire Discharge Duct Adapter — 2DDA-16
The 2DDA-16 discharge duct adapter supports installations requiring additional condenser discharge ducting.
The correct duct diameter, length, and routing configuration should be confirmed for the intended application.
Manufacturer Part Number: 2DDA-16
Contact Climate Control Solutions for pricing and availability.
OceanAire Condenser Return-Air Plenum — DCP-5
The DCP-5 condenser return-air plenum is available for installations where air must be ducted to the condenser inlet.
This accessory is useful for more specialized temporary HVAC arrangements that require controlled condenser airflow.
Manufacturer Part Number: DCP-5
Contact Climate Control Solutions for pricing and availability.
Flexible Ducting
Climate Control Solutions also offers flexible ducting for commercial portable HVAC installations.
View 16-Inch × 25-Foot Flexible Ducting
The appropriate OceanAire adapter, duct compatibility, temperature rating, and maximum permitted duct length should be confirmed before ordering.
Browse Additional HVAC Accessories
Why Choose the OceanAire 2OACH6034?
The OceanAire 2OACH6034 combines 60,100 BTU/hr of cooling, 53,500 BTU/hr of heating, and portable construction in one commercial-grade heat pump.
Its three-phase electrical configuration makes it suitable for industrial facilities equipped with 460V power.
The built-in condensate pump, automatic mode changeover, adjustable airflow, washable filters, and manufacturer-supported accessories provide additional installation flexibility.
For businesses requiring both heating and cooling throughout the year, the 2OACH6034 offers a versatile alternative to separate portable heating and air conditioning equipment.
Compare Other Portable Heating and Cooling Equipment
Climate Control Solutions supplies additional options for different electrical requirements and cooling capacities:
- OceanAire Portable Heat Pumps — Explore additional OceanAire and other commercial portable heating and cooling equipment.
- Airrex AHSC-60R 460V – 5-Ton Portable Heat Pump — Another 5-ton heating and cooling option for industrial three-phase facilities.
- Portable AC & Spot Cooler Comparison Hub — Compare commercial portable cooling equipment.
You can also browse our OceanAire product selection.
Frequently Asked Questions About the OceanAire 2OACH6034
How many BTUs does the OceanAire 2OACH6034 provide?
The 2OACH6034 delivers 60,100 BTU/hr of cooling capacity and 53,500 BTU/hr of heating capacity.
Can the 2OACH6034 both heat and cool?
Yes. The 2OACH6034 is a portable heat pump that provides both heating and cooling through a refrigeration-based heat pump system.
What electrical power does the 2OACH6034 require?
The unit operates on 460V / 60Hz three-phase electrical power and uses a NEMA L16-20P locking plug.
Can the 2OACH6034 operate from a standard 115V outlet?
No. This model requires compatible 460V three-phase electrical service.
Does the 2OACH6034 require condenser exhaust ducting?
The 2OACH6034 is air-cooled and must have an appropriate arrangement for condenser heat rejection. Depending on the installation, compatible ducting or a ceiling panel kit may be required.
What accessories are compatible with the 2OACH6034?
OceanAire identifies the CK-16 ceiling panel kit, 2NK-3 nozzle kit, DEP-16 evaporator return-air plenum, 2DDA-16 discharge duct adapter, and DCP-5 condenser return-air plenum as optional accessories.
Does the 2OACH6034 include a condensate pump?
Yes. It includes a built-in automatic condensate pump with up to 20 feet of vertical lift.
Can the 2OACH6034 cool a server room?
Yes. It can provide temporary or supplemental cooling for suitable server rooms when the cooling load, electrical service, airflow, condenser exhaust arrangement, and condensate drainage are appropriate.
Can this heat pump operate outdoors?
No. OceanAire specifies that the 2OACH6034 is not approved for outdoor operation.
What refrigerant does the 2OACH6034 use?
The published specifications list R-410A refrigerant.
What is the warranty on the OceanAire 2OACH6034?
OceanAire provides a 1-year limited full-product warranty plus 4 additional years of compressor coverage, subject to manufacturer terms.
Buy the OceanAire 2OACH6034 from Climate Control Solutions
Climate Control Solutions supplies OceanAire portable heat pumps, commercial spot coolers, and industrial climate control equipment nationwide.
Whether you need one 2OACH6034 for a manufacturing facility or multiple units for a temporary HVAC project, our team can assist with equipment selection, electrical requirements, compatible accessories, and shipping arrangements.
Contact Climate Control Solutions for current pricing, availability, and bulk-order quotes.
